1.9K Digital Movie Projection System
Main Technical Chracteristics
the system is the compaination of digital movie projection system, digital movie storage playing system and digital movie sound processing system. it totally conforms to or advanced than the standard of '' Digital movie ( medium level ) projection system technical requirements '' ( GD/J014-2007 ) conistituted by state Administration of Radio, Film and Television.
The system projection optical axis heigh axis heigh is 1250mm. And the pedestal, the customer can move the system freely. And there are also four fixing feets under the pedestal, them the system can be located frimly on the floor, and the system horizonal level can be adjusted, also the elevation and despression angle can be adjusted by them.
Projection System :
-
3 chips DLP technology : 3× 0.8 " 720p 12 DC3 ( black chip ) , the effective resolution is 1280 × 720 @ 60hz.
-
It uses full 10 bit image processing system, therefore the color number can be 71 trillion.
-
Dual lamps system : OSRAM 2×300w.
-
Under standard projection state, the uniformity is no less than 80% , and the constrast is 2000:1.
-
The real luninous flux of the video projector : no less than 6000 lumen.
-
DVI-D video input interface and available with 1920×1080 24psf format.
-
To control the video projector by IR remote controller.
-
Color temperature : 6500° k± 1000° k.
-
Both vartical lens shift and horizonal lens shift are achievable.
-
The standard matching lens size : 1.44-1.8:1, and the customer can choose the prime lens or the electrical zoom lens base on the cinema dimension.
-
Prime lens : 0.64:1 , 0.96:1.
-
Electrical zoom lens : 1.2-1.44:1, 1.8-2.4:1, 2.4-3.6:1, 3.6-5.6:1.
Storage and Playing System :
-
Embedded system, the hardware decoding rate is 50Mb/s, low power consume and reliable system.
-
The max, video image output format is 1080p/24psf.
-
Available with DVI-D digital video output.
-
Intellective electric stop movie memory playing function.
-
Multi sound channel analog audio output.
-
Available with the digital movie medium projection equipment authorized system and movie projection times or schedule management, it has the function of checking the information of projection times and schedules.
-
10 to 15 movies can be stored .
-
Both pulling hardware and USB flash memory are available to download the movie.
-
Available with 6 routes audio input terface ( cannon connector ) and 6 routes analog audio input interface ( 25 pin D type connector ).
-
Three working modes of 2-franctional frequency, 3-franctional frequency and the direct modes are achivable.
-
Using DSP technology to achieve the digital processing, and all the audio processing are digitals, then the noise can be deducated greatly.
-
IT can achieve the gain control, franctional frequency and balance processing to the digital cinema at the same time.
-
Professional digital movie decoding module.
-
Using the computer to set the processor through the professional adjusting software.
-
To compensate the archetecture acoustics bug by adjusting the balance of 6 route 31 range on the software surface.
Installation Parameters :
Total weight : 133 KG.
Outline dimension: 840 ( length ) × 555 ( width ) × 1440 ( height ).
Power supply : single phase , 220V 50Hz.
Input power: 900W. Read More
|
